Structure of Green Walnut Peeling and Washing Machine
The green walnut peeling cleaning machine mainly includes the frame part, the feeding part, the upper and lower protective cover plates, the power part of the transmission cover safety mechanism, the single-phase motor, the gearbox, the rotary part, the adjustment grille, the wire brush, and the peeling part.
Working Principle
The stirring core of the green walnut peeling machine is rotated by the pulley drive under the action of rotating water flow, which drives the green skin walnut and water to rotate by itself. During the rotation process, the walnut and the water, the blade inside the barrel, and the netting itself rub, and peel off.
Features of Green Walnut Peeling and Cleaning Machine
- Light weight, small size, and easy operation.
- Low power consumption, low noise, and high processing efficiency.
- The capacity is high, the peeling rate of walnut is as high as 99%, and the damage rate of walnut shells is about 0.5%.
- Quality assured, all parts are professionally inspected and tested, and can be used with confidence.
If you have any questions or are interested in our Machine, please feel free to contact us, we are always at your service.
More details about the walnut processing line.
Technical Parameter of fresh walnut peeler
| Model | Power | Capacity(kg/h) | Peeling rate | Damage rate | Weight | Size(mm) |
| TZ-400 | 1.5kw | 400-600 | 99% | 0.5% | 120kg | 1450*680*880 |
| TZ-600 | 2.2kw | 600-800 | 99% | 0.5% | 160kg | 1550*750*980 |
| TZ-800 | 3kw | 800-1000 | 99% | 0.5% | 230kg | 1850*850*1100 |
The inner structure of green walnut peeling machine
